Jackdaw is here to collect all information in your domain, store it in a SQL database and show you nice graphs on how your domain objects interact with each-other an how a potential attacker may exploit these interactions. It also comes with a handy feature to help you in a password-cracking project by storing/looking up/reporting hashes/passowrds/users.
Most of these commands are available already from the webapi, except for the database init.
jackdaw --sql sqlite:///<full path here>/test.db dbinit
Full enumeration with integrated sspi - windows only
jackdaw --sql sqlite:///test.db enum 'ldap+sspi://10.10.10.2' 'smb+sspi-ntlm://10.10.10.2'
Full enumeration with username and password - platform independent
The passowrd is
jackdaw --sql sqlite:///test.db enum 'ldap://TEST\victim: [email protected] ' 'smb+ntlm-password://TEST\victim: [email protected] '
LDAP-only enumeration with username and password - platform independent
The passowrd is
jackdaw --sql sqlite:///test.db ldap 'ldap://TEST\victim: [email protected] '
Start interactive web interface to plot graph and access additional features
jackdaw --sql sqlite:///<FULL PATH TO DB> nest
http://127.0.0.1:5000/ui for the API
Please see the
Building the UI section further down to learn how to build the UI. Once built:
http://127.0.0.1:5000/nest for the graph interface (shows the graph, but far from working)
LDAP enumeration phase acquires data on AD info, User, Machine, OU, Group objects which will be reprezented as a node in the graph, and as a separate table in the DB. Additionally all afforementioned objects' Security Descriptior will be parsed and the ACLs for the DACL added to the DB. This, together with the memebership information will be represented as edges in the garph. Additionally custom SQL queries can be performed on any of the afforementioned data types when needed.
SMB enumeration phase acquires data on shares, localgroups, sessions, NTLM data via connecting to each machine in the domain (which is acquired via LDAP)
via LSASS dumps (optional)
The framework allows users to upload LSASS memory dumps to store credentials and extend the session information table. Both will be used as additional edges in the graph (shared password and session respectively). The framework also uses this information to create a password report on weak/shared/cracked credentials.
via DCSYNC results (optional)
The framework allows users to upload impacket's DCSYNC files to store credentials. This be used as additional edges in the graph (shared password). The framework also uses this information to create a password report on weak/shared/cracked credentials.
via manual upload (optional)
The framework allows manually extending the available DB in every aspect. Example: when user session information on a given computer is discovered (outside of the automatic enumeration) there is a possibility to manually upload these sessions, which will populate the DB and also the result graph
The framework can generate a graph using the available information in the database and plot it via the web UI (nest). Furthermore the graph generation and path canculations can be invoked programmatically, either by using the web API (/ui endpoint) or the grph object's functions.
The framework can identify common AD misconfigurations without graph generation. Currently only via the web API.
User anomalies detection involve detection of insecure UAC permissions and extensive user description values. This feature set is expected to grow in the future as new features will be implemented.
Machine anomalies detection involve detection of insecure UAC permissions, non-mandatory SMB singing, outdated OS version, out-of-domain machines. This feature set is expected to grow in the future as new features will be implemented.
The framework is not performing any cracking, only organizing the hashes and the cracking results
currently main focus is on impacket and aiosmb's dcsync results !NT and LM hashes only!
Sample porcess is the following:
This project is in experimental phase! This means multiple things:
Jackdaw uses SQLAlchemy ORM module, which gives you the option to use any SQL DB backend you like. The tests are mainly done on SQLite for ovbious reasons. There will be no backend-specific commands used in this project that would limit you.
Building the UI
THIS IS ONLY NEEDED IF YOU INSTALL VIA GIT AND/OR CHANGE SOMETHING IN THE UI CODE
The UI was written in React. Before first use/installation you have to build it. For this, you will need
npm installed. Then:
npm run buildOnce done with the above, the UI is ready to play with.
"If I have seen further it is by standing on the shoulders of Giants."
For the original idea
For the ACL edge calculation
@dirkjanm ( https://github.com/dirkjanm/ )
For the awesome UI
Zsolt Imre ( https://github.com/keymandll )
In case I forgot to mention someone pls send a PR
